Blower Motor: Service and Repair

Fig. 16 Blower Motor Replacement:

Instrument Panel, Gauges and Warning Indicators
Restraints and Safety Systems

Remove blower motor in numbered sequence, Fig. 28, noting the following:
1. Clean blower case before installation.
2. Reverse procedure to install.
