Cooper S Convertible (R52) L4-1.6L SC (W11)
>>
Repair and Diagnosis
>>
Diagrams
>>
Electrical Diagrams
>>
Body
>>
Lighting
>>
Headlight Widening Adjustment
>>
Servomotor, Right
>>
Manual Headlight Vertical Aim Control (Without Xenon Light, Right)
Manual Headlight Vertical Aim Control (Without Xenon Light, Right)
Manual headlight vertical aim control Part 1:
Manual headlight vertical aim control Part 2:
