Wiper Pivot: Service and Repair

Removing And Installing Complete Wiper Console

Remove cowl panel cover.







Release Nut (1).

Install hint:
Ensure bracket is located correct to grommet.

Remove screws (2).

Install hint: (All fixings)
Tightening Torque 10 Nm.

Disconnect connector of motor and remove wiper mechanism/motor.
