Mini
>>
2005
>>
Cooper S Convertible (R52) L4-1.6L SC (W11)
>>
Repair and Diagnosis
>>
Diagrams
>>
Electrical Diagrams
>>
Body
>>
Restraint Functions (Without MRS Multiple Restraint System V)
>>
Seat Belt
>>
Front Passenger's Seat Belt Contact
>>
Front Passenger Belt Buckle Contact Switch (Up to 01/05)
Front Passenger Belt Buckle Contact Switch (Up to 01/05)
Front passenger belt buckle contact switch:
