Cooper S (R53) L4-1.6L SC (W11)
>>
Repair and Diagnosis
>>
Diagrams
>>
Electrical Diagrams
>>
Body
>>
Locking and Security Functions
>>
Antitheft Alarm System
>>
Switch, Driver's Door
>>
Driver's Door Lock Motor (Up to 03/02)
Driver's Door Lock Motor (Up to 03/02)
Driver's door lock motor Part 1:
Driver's door lock motor Part 2:
