Home >> Mini >> 2002 >> Cooper S (R53) L4-1.6L SC (W11) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Communication >> Telephone Provisions >> Antenna/Hands-Free Function (Up to 03/02)

Antenna/Hands-Free Function (Up to 03/02)

Antenna/hands-free function:
