Test H: The Yellow Anti-Lock Brake System (ABS) Warning Indicator Does Not Self-Check

Test H: The Yellow Anti-Lock Brake System (ABS) Warning Indicator Does Not Self-Check

Refer to Vehicle/Diagrams for schematic and connector information.

Normal Operation
When the ignition switch is turned to the ON or START position, the instrument cluster illuminates the yellow anti-lock brake system (ABS) warning indicator. Once the ABS module has performed a self-check, a message is sent to the instrument cluster to turn the indicator off.

Possible Cause
^ Instrument cluster

H1:
