Lifter / Lash Adjuster: Service and Repair

Hydraulic Lash Adjuster

Material:

Material

Removal and Installation
1. Remove the camshaft roller followers.

2. NOTE: Mark the positions of the hydraulic lash adjusters to make sure they are assembled in their original positions.

Remove the hydraulic lash adjusters.

3. NOTE: Inspect the hydraulic lash adjusters for scoring marks and uneven wear in the bore. Install new lash adjusters if necessary.

To install, reverse the removal procedure.
^ Lubricate the hydraulic lash adjusters with clean engine oil.
