Floor Console - Rear

FLOOR CONSOLE - REAR







Removal and Installation
1. Remove the 4 rear floor console bolts.
- To install, tighten to 10 Nm (89 lb-in).

2. Remove the rear floor console.
3. To install, reverse the removal procedure.
