Test V: An Individual Fog Lamp Is Inoperative

PINPOINT TEST V: AN INDIVIDUAL FOG LAMP IS INOPERATIVE

V1:

Normal Operation
The fog lamps are grounded through circuit 1205 (BK).

Possible Causes
- An open in circuit 1205 (BK)
- Lamp
