Home >> Mercury >> 2004 >> Sable V6-3.0L VIN 2 Flex Fuel >> Repair and Diagnosis >> Engine, Cooling and Exhaust >> Engine >> Engine Lubrication >> Oil Pan >> Service and Repair >> Oil Pan Baffle

Oil Pan Baffle

Oil Pan Baffle
1. Remove the oil pan.





2. Remove the seven nuts and remove the oil pan baffle.
3. To install, reverse the removal procedure.
