Test E: Trans. Control Indicator Lamp (TCIL) Is Illuminated Continuously





PINPOINT TEST E: THE TRANSMISSION CONTROL INDICATOR LAMP (TCIL) IS ILLUMINATED CONTINUOUSLY
