Rear Seat Backrest Latch

REMOVAL
1. Remove the seat cushion. For additional information, refer to Seat Cushion.

NOTE: The 60 percent portion is shown, the 40 percent seat is similar.

2. Remove the rear seat backrest. For additional information, refer to Rear Seat Backrest-Full Backrest, Four Door.
3. Disassemble the rear seat backrest. For additional information, refer to Rear Seat Backrest-Full Backrest, Four Door.







4. Remove the bolts and the latch.

INSTALLATION
1. To install, reverse the removal procedure.

NOTE: Make sure the safety belt webbing is not twisted prior to installation.

2. Check the restraint system for correct operation.
