Center Finish Panel

REMOVAL
1. Disconnect the battery ground cable. For additional information, refer to Battery.
2. Apply the parking brake.
3. If equipped with floor selector lever, position the selector lever in 1.
4. Remove the integrated control panel. For additional information, refer to Radio, Stereo and Compact Disc.







5. Remove the instrument panel lower steering column cover.
1 Remove the bolts.
2 Remove the instrument panel lower steering column cover.

6. Remove the ashtray.







7. Remove the instrument panel center finish panel.
1 Remove the screws.
2 Remove the instrument panel center finish panel.
- Disconnect the electrical connector by reaching through the ICP opening.

NOTE: When installing the instrument panel center finish panel, be sure the alignment tabs are positioned correctly.

INSTALLATION
1. To install, reverse the removal procedure.
