Rear Suspension

Rear Suspension
At regular intervals, the following rear suspension checks should be made:
1. Check for evidence of fluid leaks on the rear struts. (A light film of fluid is permissible. Verify fluid is not from other sources).
2. Check the rear strut operation.
3. Check the condition of the upper and lower rear suspension arm bushings and rear suspension tension strut and bushings.
