A/C Cycling Switch

REMOVAL







1. Remove the screws and reposition the power steering pump reservoir.







2. Disconnect the A/C cycling switch electrical connector.







3. Remove the A/C cycling switch from the top of the suction accumulator/drier.

INSTALLATION
1. To install, reverse the removal procedure.
- Lubricate the O-ring seals with PAG Compressor Oil YN-12-C or equivalent meeting Ford specification WSH-M1C231-B.
