Built Before May 24, 1999

Diagram 412-03-00-1:

Air Temperature Actuator
Central Junction Box
Fuse F23
Fuse F37
Heater Blower Motor
Heater Blower Relay
Heater Blower Series Resistor
Heater Blower Switch
Heater Mode Switch
Temperature Door Variable Resistor

Diagram 412-03-00-2:

A/C Compressor Clutch
A/C Compressor Clutch Diode
A/C Compressor Cycling Switch
A/C Wide Open Throttle Relay
Battery Junction Box
Dual Pressure Switch
Powertrain Control Module
Powertrain Control Module Power Relay

Diagram 412-03-00-3:

Battery Junction Box
Dual Pressure Switch
Engine Cooling Fan Motor
Engine Cooling Fan Relay
Engine Cooling Fan Resistor
Fuse F2
High Speed Engine Cooling Fan Relay
Powertrain Control Module Power Relay
Powertrain Control Module
Second Cooling Fan Motor
