Locator Rod Bushing, Replacement

REMOVAL
1. Remove the stabilizer bar and support nut.





2. Remove the stabilizer bar and support from the transaxle.





3. Pull the transmission gear shift stabilizer bushing out of the stabilizer bar.





INSTALLATION
To install, reverse the removal procedure.
