Removal

1. Disconnect battery ground cable. Remove access cover from rear of roof trim panel.

2. Disconnect sliding roof panel motor electrical connectors.

3. NOTE: Once sliding roof panel motor is removed, it must be synchronized (timed) as described under Adjustments.

Remove sliding roof panel motor and retaining screws. Remove sliding roof panel motor.
