Home >> Mercury >> 1997 >> Sable V6-183 3.0L DOHC VIN S MFI >> Repair and Diagnosis >> Sensors and Switches >> Sensors and Switches - Wiper and Washer Systems >> Wiper Switch >> Service and Repair >> Rear Wiper/Washer Switch

Rear Wiper/Washer Switch

REMOVAL
1. Remove rear windshield wiper/washer switch from instrument panel by pulling straight out.
2. Disconnect wiring connector from rear windshield wiper/washer switch.

INSTALLATION







1. Follow removal procedure in reverse order.
