Front Door Panel: Service and Repair

See TSB 99-18-15

Trim Panels, Door
Front
Removal and Installation
1. Disconnect battery ground cable.






Contour







Mystique

2. Remove outside rear view mirror mounting hole cover retaining screw. Remove rear view mirror mounting hole cover (17K709).
3. Remove one screw retaining front door handle cup to front door trim panel (23942).
4. Pull front door handle cup from front door trim panel and disconnect wiring harness from switches. Remove front door handle cup.
5. Remove arm rest cover and two screws retaining arm rest
6. Remove screws retaining front door trim panel to front door (20124).
7. Lift front door trim panel and remove from front door.
8. To install reverse Removal procedure.
