Home >> Mercury >> 1993 >> Cougar/XR7 V6-232 3.8L >> Repair and Diagnosis >> Wiper and Washer Systems >> Testing and Inspection >> Component Tests and General Diagnostics >> Wiper/Washer Diagnosis >> Test B7 - B12

Test B7 - B12

Fig. 34 Diagnostic Pinpoint Test B, Washer Does Not Operate. Thunderbird/Cougar, Mustang, Tempo/Topaz:
