Windshield Wipers - Torque Value Revision

91ford08

Article No. 91-5B-15


SHOP MANUAL - 1991 - PAGE 01-16A-14 - FRONT WINDOW WIPER SPECIFICATION TABLE TORQUE VALUES REVISED TO LB.IN.


FORD: 1991 ESCORT

LINCOLN-MERCURY: 1991 TRACER





ISSUE: The Torque Specifications chart under Front Window Wipers Removal/installation procedures Specifications, Page 01-16A-14 of the 1991 Escort/Tracer Shop Manaual, incorrectly indicates the readings as Lb.ft. The correct heading in the chart should read Lb.in.


ACTION: Refer to the pages following this TSB article for the revised chart.


OTHER APPLICABLE ARTICLES: NONE
WARRANTY STATUS: INFORMATION ONLY
OASIS CODES: 190000
