With Analog Instrument Cluster

Removal and Installation
1. Disconnect battery ground cable.
2. Remove ignition lock cylinder assembly to permit removal of steering column shrouds.
3. Remove steering column trim shrouds.
4. Remove screws retaining lower LH and radio finish panels (one screw each) and remove panels by snapping out.
5. Remove seven cluster opening finish panel retaining screws, and one jam nut behind headlamp switch. Remove finish panel by rocking upper edge toward driver.
6. On column shift vehicles only, disconnect transmission selector indicator cable from column (one screw and cable loop).
7. Disconnect upper speedometer cable from lower speedometer cable in engine compartment.
8. Remove four screws retaining cluster to instrument panel and pull cluster assembly forward.
9. Disconnect cluster electrical connectors and speedometer cable. Press cable latch to disengage cable from speedometer head, while pulling cable away from cluster. Remove cluster.
10. To install, reverse Steps 1 through 9 and calibrate the transmission selector indicator using the thumbwheel.
