Cougar/XR7 V6-232 3.8L
>>
Repair and Diagnosis
>>
Engine, Cooling and Exhaust
>>
Cooling System
>>
Testing and Inspection
>>
KF28 - Check EDF Power-to-Fan Circuit For Short to Power
KF28 - Check EDF Power-to-Fan Circuit For Short to Power
Fig. 5k Fan Pinpoint Test KF28:
