Home >> Mercury >> 1989 >> Sable V6-182 3.0L >> Repair and Diagnosis >> Cruise Control >> Testing and Inspection >> Pinpoint Tests >> D: Speed Does Not Increase >> D5-D6

D5-D6

Fig. 44 Speed Does Not Increase During Dynamic Test, Pinpoint Test D:
