IGN 8 System Check - With Engine Analyzer Equipment
>>
Test 3 Spark Plug Wire Resistance
Test 3 Spark Plug Wire Resistance
Fig. 8j Ignition system diagnosis, system check using engine analyzer (Part 10 of 10):
