Parts Ordering and Labor Times Instructions

Attachment 1 Page 2 of 2

PARTS ORDERING:

Service parts required for this program must be ordered through normal channels.

Service Part Repair Code Class
Number Number

E9GZ-6A666-A A BG

E9GZ-6A666-B B BG

E9GZ-6A666-C C BG

"SG" 5W-30 *Oil, Engine - 4 Quarts Required. V

*Engine Oil is to be claimed only when Repair Codes "B" or "B" and "C" are performed.

LABOR TIMES
Hours Labor
Operation

Inspect for Oil Sludge Deposit Level and
Install Repair Code "A" Parts. 0.4 B88A

Inspect for Oil Sludge Deposit Level and
Install Repair Code "A" and "B" Parts. 2.0 B88B

Inspect for Oil Sludge Deposit Level and
Install Repair Code "A", "C" and "B" Parts. (Note repair sequence.) 2.2 B88C


Removed Parts Return: Retain Removed Parts Per Warranty and Policy Manual Instructions.
