Mercury
>>
1986
>>
Sable V6-182 3.0L
>>
Repair and Diagnosis
>>
Sensors and Switches
>>
Sensors and Switches - HVAC
>>
Solar Sensor
>>
Locations
Solar Sensor: Locations
Location View - Instrument Panel Wiring (Sable):
Top LH Side Of I/P
Applicable to: 1986 Sable Models
