Mercury
>>
1984
>>
Topaz L4-140 2.3L HSC
>>
Repair and Diagnosis
>>
Powertrain Management
>>
Emission Control Systems
>>
Diagrams
>>
Vacuum and Vapor Hose Diagrams
>>
EEC-IV Vacuum Hose Routing
>>
HSC Engine W/Feedback Carburetor & Auto. Transmission
HSC Engine W/Feedback Carburetor & Auto. Transmission
Fig. 44 EEC-IV Vacuum Hose Routing. 1984 4-140 High Swirl Combustion Engine W/Feedback Carburetor & Automatic Transmission:
