Calibration:4-14B-R11 Motorcraft 2150 E4CE-9510-AA (A/C) E4CE-9510-BA (Non A/C)

MODEL YEAR: 1984 ENGINE: 3.8L
CARBURETOR SPECIFICATIONS

Model: Motorcraft 2150
Part Number: E4CE-9510-AA (A/C) E4CE-9510-BA (Non A/C)

CHOKE/FUEL ENRICHMENT SYSTEM
Pulldown Setting: .103"
Bi-Metal Identification: 2065KE350
Fast Idle Cam Setting: V-Notch
Fast Idle Cam Identification: HF
Choke Plate Lever Setting: Std.
De-Choke: .25" Minimum
Choke Cap Setting: V-Notch (2 NR)
Choke Lever Identification: E2

FUEL INLET SYSTEM
Float Setting (Dry): 7/16"
Float Level (Wet): .810"

PUMP SYSTEM
Pump Lever Location: #3

MAIN METERING SYSTEM
Enrichment Valve Identification: Red
Fuel Bowl Vent Valve: 3/8" Open Tube
Main Jet: 47 F
DISTRIBUTOR SPECIFICATIONS Total Advance @ 2500 RPM Includes Initial Timing

Distributor Part No: E4AE-12127-AA
Initial Timing (~BTDC): 12
Vac Advance Connected: 38-48
Vac Advance Disconnected: 17-22

PROPANE SPECIFICATIONS (Set in Neutral)

Gain RPM: 30-90
Reset RPM: 60
