Calibration:4-25G-R13 Holley 1949 E43E-9510-ADA (A/C) E43E-9510-Aea (Non A/C)

MODEL YEAR: 1984 ENGINE: 2.3L
CARBURETOR SPECIFICATIONS

Model: Holley 1949
Part Number: E43E-9510-ADA (A/C) E43E-9510-AEA (Non A/C)

CHOKE/FUEL ENRICHMENT SYSTEM
Pulldown Setting: .080 -.120" w/Modulator

Bi-Metal Identification: Spring Compressed
Fast Idle Cam Index: #509

Fast Idle Cam Identification: .020-.030"

De-Choke: 4 Step Black
Come-Off Time: .180-.220"
Choke Cap Setting: 4 min Maximum (2 NR) with Tamper Resistant Gray Spacer

FUEL INLET SYSTEM

Fuel Level (Dry): Both float pontoons at outboard edge flush with surface of main body casting (without gasket)

PUMP SYSTEM
Pump Lever Location: #2



DISTRIBUTOR SPECIFICATIONS Total Advance @ 2500 RPM Includes Initial Timing
Distributor Part No: E43E-12127-DA
Initial Timing (~BTDC):
10
Vac Advance Connected: 27-37
Vac Advance Disconnected: 14-18
PROPANE SPECIFICATIONS (Set in Neutral)

Gain RPM: 20-80
Reset RPM: 50
