Calibration:4-61F-R00

MODEL YEAR: 1983 - ENGINE: 2.8L
CARBURETOR SPECIFICATIONS

Model: Motorcraft 2150
Part Number: E37E-9510-ABA

CHOKE/FUEL ENRICHMENT SYSTEM
Pulldown Setting: .136 +/- .010"
Bi-Metal Identification: PC065ME
Fast Idle Cam Setting: V-Notch
Fast Idle Cam Identification: 2F
Choke Plate Lever Setting: Std.
De-Choke: .250" Minimum
Choke Cap Setting: V-Notch
Choke Lever Identification: E2

FUEL INLET SYSTEM
Float Setting (Dry): 7/16"
Float Level (Wet): .810"

PUMP SYSTEM
Pump Lever Location #4

MAIN METERING SYSTEM
Enrichment Valve Identification: Brown/Silver
Fuel Bowl Vent Valve: 3/8" Open Tube
Main Jet: 50 F
