Calibration:3-49T-R20

MODEL YEAR: 1983 - (4 x 2) - ENGINE: 2.3L
CARBURETOR SPECIFICATIONS Model:

Part Number: Carter YFA E37E-9510-NB

CHOKE/FUEL ENRICHMENT SYSTEM Pulldown Setting:
Bi-Metal Identification: .320"
Cam Index Setting: REL

Fast Idle Cam Identification: .140

De-Choke: - 498
Choke Cap Index Plate Color: .27" Minimum Grey

FUEL INLET SYSTEM
Float Setting (Dry):
.650~
DISTRIBUTOR SPECIFICATIONS Total Advance @ 2500 RPM Includes Initial Timing
Distributor Part No: E27E-12127-AA Initial Timing (~BTDC):
Vac Advance Connected: 6

Vac Advance Disconnected: 34-45 13-18

PROPANE SPECIFICATIONS (Set in Neutral)

Gain RPM:
Reset RPM: 20-30 30



MODEL YEAR: 1983 - (4 x 4) - ENGINE: 2.3L
CARBURETOR SPECIFICATIONS

Model: Carter YFA
Part Number: E37E-9510-NB

CHOKE/FUEL ENRICHMENT SYSTEM
Pulldown Setting: .320"
Bi-Metal Identification: REL
Cam Index Setting: .140
Fast Idle Cam Identification: -498
De-Choke: .27" Minimum
Choke Cap Index Plate Color: Grey

FUEL INLET SYSTEM
Float Setting (Dry): .650"
DISTRIBUTOR SPECIFICATIONS Total Advance @ 2500 RPM Includes Initial Timing

Distributor Part No: E27E-12127-AA
Initial Timing (~BTDC): 6
Vac Advance Connected: 34-45
Vac Advance Disconnected: 13-18

PROPANE SPECIFICATIONS (Set in Neutral)

Gain RPM: 20-30
Reset RPM: 30
