Calibration:3-14N-R04

MODEL YEAR: 1983 - ENGINE: 3.8L
CARBURETOR SPECIFICATIONS

Model: Motorcraft 2150
Part Number: E3SE-9510-JA (A/C or Non A/C) E3SE-9510-ANA (A/C or Non A/C Alt.) E3SE-9510-KA (Non A/C) E3SE-9510-APA (Non A/C Alt.)

CHOK/FUEL ENRICHMENT SYSTEM
Pulldown Setting: .101"
Bi-Metal Identification: 2080ME350
Fast Idle Cam Setting: V-Notch
Fast Idle Cam Identification: H
Choke Plate Lever Setting: Std.
De-Choke: .25" Minimum
Choke Cap Setting: V-Notch
Choke Lever Identification: E2

FUEL INLET SYSTEM
Float Setting (Dry): 7/16"
Float Level (Wet): .810"

PUMP SYSTEM
Pump Lever Location: #3

MAIN METERING SYSTEM
Enrichment Valve Identification: Purple
Fuel Bowl Vent Valve: 3/8" Open Tube
Main Jet: 47F
DISTRIBUTOR SPECIFICATIONS Total Advance @ 2500 RPM Includes Initial Timing

Distributor Part No: E3SE-12127-DA
Initial Timing (~BTDC): 10
Vac Advance Connected: 36-46
Vac Advance Disconnected: 15-19


PROPANE SPECIFICATIONS (Set in Neutral)

Gain RPM: 50-150
Reset RPM: 100
