Calibration:3-14C-R10

MODEL YEAR: 1983 - ENGINE: 3.8L
CARBURETOR SPECIFICATIONS

Model: Motorcraft 2150
Part Number: E3SE-9510-BDA (A/C) E3SE-9510-BEA (Non A/C)

CHOKE/FUEL ENRICHMENT SYSTEM
Pulldown Setting: .107"
Bi-Metal Identification: 2080ME350
Fast Idle Cam Setting: V-Notch
Fast Idle Cam Identification: H
Choke Plate Lever Setting: Std.
De-Choke: .25" Minimum
Choke Cap Setting: V-Notch
Choke Lever Identification: E2

FUEL INLET SYSTEM
Float Setting (Dry): 7/16"
Float Level (Wet): .810"

PUMP SYSTEM
Pump Lever Location: #3

MAIN METERING SYSTEM
Enrichment Valve Identification: Purple
Fuel Bowl Vent Valve: 3/8" Open Tube
Main Jet: 47F
DISTRIBUTOR SPECIFICATIONS Total Advance @ 2500 RPM Includes Initial Timing

Distributor Part No: E3ZE-12127-FA
Initial Timing (~BTDC): 10
Vac Advance Connected: 38-51
Vac Advance Disconnected: 15-21

PROPANE SPECIFICATIONS (Set in Neutral)

Gain RPM: 30-90
Reset RPM: 60
