Calibration:3-06N-R10

MODEL YEAR: 1983 - ENGINE: 2.3L
CARBURETOR SPECIFICATIONS

Model: Carter YFA
Part Number: E3ZE-9510-ACA (A/C or Non A/C) E3ZE-9510-ABA (Non A/C)

CHOKE/FUEL ENRICHMENT SYSTEM
Pulldown Setting: .260"
Bi-Metal Identification: RER-3
Cam Index Setting: .140
Fast Idle Cam Identification: 8510
De-Choke: .22" Minimum
Choke Cap Index Plate Color: Yellow

FUEL INLET SYSTEM
Float Setting (Dry): .650"
DISTRIBUTOR SPECIFICATIONS Total Advance @ 2500 RPM Includes Initial Timing

Distributor Part No: E0EE-12127-BA
Initial Timing (~BTDC): 12
Vac Advance Connected: 33-43
Vac Advance Disconnected: 19-25

PROPANE SPECIFICATIONS (Set in Neutral)

Gain RPM: 160-240
Reset RPM: 200
