Calibration:3-54J-R10 Motorcraft 2150 E3TE-9510-BSA
MODEL YEAR: 1983 ENGINE: 5.0L
CARBURETOR SPECIFICATIONS
Model: Motorcraft 2150
Part Number: E3TE-9510-BSA
CHOKE/FUEL ENRICHMENT SYSTEM
Pulldown setting: .137"
Bi-Metal Identification:
2100MF
Fast Idle Cam Setting: V-Notch
Fast Idle Cam Identification: X
Choke Plate Lever Setting: Std.
De-Choke:
.25" Minimum
Choke Cap Setting: V-Notch
Choke Lever Identification: E
FUEL INLET SYSTEM
Float Setting (Dry):
7/16"
Float Level (Wet):
.810"
PUMP SYSTEM
Pump Lever Location: #4
MAIN METERING SYSTEM
Enrichment Valve Identification: Red/Silver
Fuel BowL Vent Valve: 3/8" Open Tube
Main Jet: 50F
DISTRIBUTOR SPECIFICATIONS Total Advance @ 2500 RPM Includes Initial Timing
Distributor Part No: E3TE-12127-AAA
Initial Timing (~BTDC): 8
Vac Advance Connected: 33-44
Vac Advance Disconnected: 16-21
PROPANE SPECIFICATIONS (Set in Neutral)
Gain RPM: 20-100
Reset RPM: 60
