Calibration:3-54E-R10 Motorcraft 2150 E3TE-9510-BSA

MODEL YEAR: 1983 ENGINE: 5.0L
CARBURETOR SPECIFICATIONS

Model: Motorcraft 2150
Part Number: E3TE-9510-BSA

CHOKE/FUEL ENRICHMENT SYSTEM
Pulldown Setting: .137"
Bi-Metal Identification: 2100MF
Fast Idle Cam Setting: V-Notch
Fast Idle Cam Identification: X
Choke Plate Lever Setting: Std.
De-Choke: .25" Minimum
Choke Cap Setting: V-Notch
Choke Lever Identification: E

FUEL INLET SYSTEM
Float Setting (Dry): 7/16"
Float Level (Wet): .810"

PUMP SYSTEM
Pump Lever Location: #4

MAIN METERING SYSTEM
Enrichment Valve Identification: Red/Silver
Fuel Bowl Vent Valve: 3/8" Open Tube
Main Jet: 50F
DISTRIBUTOR SPECIFICATIONS Total Advance @ 2500 RPM Includes Initial Timing

Distributor Part No: E2TE-12127-MA
Initial Timing (~BTDC): 8
Vac Advance Connected: 28-37
Vac Advance Disconnected: 14-19

PROPANE SPECIFICATIONS (Set in Neutral)

Gain RPM: 20-100
Reset RPM: 60
