Engine - Choke Loading/High Idle Speed
83ford16Article No. 83-9-6
IDLES ROUGH - CHOKE LOADING 3.8L CANADIAN AND ALTITUDE
FORD 1982 GRANADA AND T-BIRD
LINCOLN-MERCURY 1982 COUGAR AND XR7
Choke loading at cold ambients and/or high curb idle with A/C off may be alleviated by changing the electrical supply to the choke to provide 12 volts.
Calibrations Affected: 2-14X, 2-14W, 2-14H & 2-14J
Inspect the oil pressure switch (9278-top left front of engine). If the switch is a single wire continue with the revision. If the switch is a 3 wire, DO NOT proceed, the rework will not correct the concern.
1. For both Canadian and altitude vehicles, replace the oil pressure switch with E0AZ-9278-A (3 wire). With a 1-1/16" socket, install the switch and torque to 8-18 ft.lbs.
2. Canadian vehicles - replace the engine wiring harness with E2DZ-14289-U (A/C) and E2DZ- 14289-V (non A/C).
3. Altitude vehicles only - replace the engine wiring harness with E2DZ-14289-T (A/C) and E2DZ-14289-S (non A/C).
4. Canadian and altitude (all) - replace the 14305 alternator rectifier wiring assembly with E2DZ-14305-
C. The original wiring assembly provided 7.2V to the choke. This new wiring assembly provides direct 12 V feed to the choke and interconnects to the engine compartment headlight wiring assembly.
5. Verify engine A/C off - on speeds to the specification on the engine decal.
Obtain an Authorized Modifications decal and list the date, dealer number and summary of alterations performed. Select a prominent place adjacent to the Vehicle Emission Control Information decal suitable for installing the Authorized Modifications decal. Clean the area, install the decal and cover it with a clear plastic decal shield.
PART NUMBER PART NAME CLASS
E0AZ-9278-A Oil Pressure Switch A
E2DZ-14289-U (A/C Canada) Harness ZC
E2DZ-14289-V (Non A/C Canada) Harness ZC
E2DZ-14289-T (A/C Altitude) Harness C
E2DZ-14289-S (Non A/C Altitude) Harness C
E2DZ-14305-C Alternator Harness C
OTHER APPLICABLE ARTICLES: None
WARRANTY STATUS: Reimbursable within the provisions of the Warranty and Policy Manual.
OPERATION: SP1428982
TIME: Replace Switch - 0.4 Hr. Replace Harness - 0.3 Hr. Reset Engine Speed - 0.2 Hr. DLR. CODING: Basic Part No. DRIVE Code: H6
