AR33.30-P-0469SYZ Remove/Install Pinion Housing With Drive Pinion

AR33.30-P-0469SYZ Remove/Install Pinion Housing With Drive Pinion
MODEL 204.08 /09 /28 /29 /38 /98, 207.38, 212.08 /09 /28 /29, 218.39
MODEL 216, 221 with 4MATIC





1 Front axle transmission
2 Pinion housing
2a Spacer washer
2d Sealing ring
2f Retaining ring
2s Bolts
4 Drive flange

f Milled area














602 589 00 33 00
Impact extractor





221 589 04 33 00
Extraction tool
