AR09.41-P-1310SXI Remove/Install Charge Air Manifold

AR09.41-P-1310SXI Remove/install Charge Air Manifold
- ENGINES 642 in MODEL 207, 212, 218, 221







1 Fuel lines
2 Leak oil line
3 Fuel lines
4 Rail leak oil line
5 Fuel pipe
6 Fuel supply line
7 Distributor leak oil line
19/2 Connecting line







8 Electrical connector
9 Electrical connector
10 Electrical connector
11 Screw
12 Engine wiring harness
13 Charge air distribution pipe
Y27/9 Exhaust gas recirculation actuator























129 589 00 91 00, Set of stop plugs
