AR01.45-P-7500-06SXI Bolt Plan For Oil Pan



AR01.45-P-7500-06SXI Bolt Plan For Oil Pan








1 Unscrew and screw in bolts (1 to 4) in the specified sequence.

Pay attention to different bolt lengths and bolt diameters.

1 Bolt M6B30
2 Bolt M6B40
3 Bolt M6B60
4 Bolt M8B25
