Engine Oil Pressure: Testing and Inspection

AR18.00-P-1250SXI Check Oil Pressure
-ENGINES 642 in MODEL 207, 212, 218, 221





Shown on engine 642 in model 203

1 Pressure gage gage
2 Pressure hose
3 Adapter fitting for oil pressure
4 Screw plug
5 Sealing ring
6 Remote thermometer
7 Tester cap

















103 589 00 21 01
Pressure gage





642 589 00 09 00
Wrench socket





124 589 07 21 00
Remote thermometer





642 589 00 91 00
Tester cap
