AR35.10-P-0042SX Remove/Install Rear Rubber Bushing of Rear Axle Mount

AR35.10-P-0042SX Remove/Install Rear Rubber Bushing Of Rear Axle Mount
MODEL 221
- except CODE (Z07) Top protection
MODEL 216





1 Rubber bushing
1s Screw
4 Rear axle carrier
50 Differential





01 Thrust piece
02 Support
05 Spindle
012 Retaining belt
013 Hydraulic hose
014 Hand pump
015 Hollow cylinder
1 Rubber bushing
4 Rear axle carrier





03 Thrust piece
04 Support
05 Spindle
011 Sleeve
012 Retaining belt
013 Hydraulic hose
015 Hollow cylinder
1 Rubber bushing
4 Rear axle carrier

















221 589 00 43 00
Extraction and insertion tool





652 589 00 33 21
Hand pump





652 589 00 33 22
Hollow cylinder





652 589 00 33 23
Hydraulic hose (complete)





001 589 01 63 00
Retaining belt
