GF54.30-P-3150SX Communication and Telephone Menu Item, Function



GF54.30-P-3150SX Communication And Telephone Menu Item, Function
- with CODE (388) Telephone "Handy", UPCI system
- with CODE (386) Preinstallation for telephone "Handy", UPCI system
- with CODE (494) USA version


"Tel"[Telephone] menu item
If the "Tel" menu item is activated in the main menu row, then the communication application last carried out is started. Should another communication application be started, then a change into the main menu row must be made again and the "Tel" menu item selected.
The telephone function can also be started by pressing the telephone/navigation quick select button (A40/9s5) on the front central operating unit (A40/9).

The following functions can be used:
^ "Telephone"
Configuring and using the telephone system
^ "Address book"
Administration menu for the address book (settings, search lists, creation of new entries)
^ "SMS"
Used to receive, write and read SMS messages
^ "WAP"only on vehicles with code (386) Preinstallation for telephone "Handy", UPCI system and with code (388) Telephone "Handy", UPCI system
Configuring and using WAP
^ "Telephone OFF"
Switches the communication application off
