GF27.60-P-3019AHC Torque Converter Lockup Clutch Control Pressure, Function

GF27.60-P-3019AHC Torque converter lockup clutch control pressure, function
- Transmission 722.902/904/906/908


Function requirements
^ Circuit 87 ON
^ Circuit 61 ON

General
The torque converter lockup clutch is operated at specified slip speeds. In order to make this possible, the variable control pressure has to be applied to the torque converter lockup clutch regulating valve.

The torque converter lock-up clutch control pressure is adapted to the respective operating condition via the torque converter lockup clutch control solenoid valve (Y3/8y8) which is actuated by the fully integrated transmission control unit (Y3/8n4).
