GF82.85-P-2040CA Video Mode, Function

GF82.85-P-2040CA Video Mode, Function
- with CODE (512) COMAND APS with DVD changer
- with CODE (527) COMAND APS with single DVD drive (with navigation)
- with CODE (528) COMAND with DVD changer


Function requirements for video mode
^ Circuit 30g ON
^ COMAND controller unit (A40/3) activated via "ON" button
^ "Video" function key actuated
^ Appropriate data storage device present in DVD drive

The video mode function is only available when the vehicle is stationary (v < 5 km/h). When the vehicle is moving, only acoustic playback remains active and - for safety reasons - a warning is shown on the Audio/COMAND display (A40/8).

Video mode, general
The DVD drive of the COMAND controller unit supports playback of video DVDs. A DVD changer is integrated into the COMAND controller unit with code (512) COMAND APS incl. DVD changer or with code (528) COMAND incl. DVD changer and a single DVD drive is installed with code (527) COMAND APS with single DVD drive (with navigation). The video image is shown in the Audio/ COMAND display once the "VIDEO" menu and then the "DVD- Video" submenu have been activated.

The system can be operated using the:
- Audio/COMAND control panel (A40/9)
- Control fields on the COMAND controller unit

Function sequence for video mode
The video signals are transmitted via a separate video line to the COMAND controller unit. The COMAND controller unit transmits the picture data to the Audio/COMAND display via a low voltage differential signaling (LVDS) line. The audio signals on vehicles with code (810) Sound system, are sent over the Media Orient System Transport (MOST) to the sound system amplifier control unit (N40/3) where they are amplified and then processed to match the stored tone settings.

On vehicles with code (810) Sound system, the audio signals are output by the COMAND controller unit over the MOST to the sound system amplifier control unit and from there, to the following speakers via direct lines:
- Left door tweeter (H4/1h1)
- Left door bass speaker (H4/1h2)
- Right door tweeter (H4/2h1)
- Right door bass speaker (H4/2h2)
- Left rear tweeter (H4/3h1)
- Left rear bass speaker (H4/3h2)
- Right rear tweeter (H4/4h1)
- Right rear bass speaker (H4/4h2)
- Center dashboard speaker (H4/27)
- Rear shelf bass speaker (H4/29)
- Left rear surround speaker (H4/54)
- Right rear surround speaker (H4/57)

On vehicles without code (810) Sound system, the audio signals are output over direct lines by the COMAND controller unit to the following speakers:
- Left door tweeter
- Left door bass speaker
- Right door tweeter
- Right door bass speaker
- Left rear tweeter
- Left rear bass speaker
- Right rear tweeter
- Right rear bass speaker
