GF54.30-P-3140SXA Video Menu Item, Function

GF54.30-P-3140SXA Video Menu Item, Function
- with CODE (863) Digital/analog TV tuner
- with CODE (527) COMAND APS with single DVD drive (with navigation)


"Video" menu item
If the "Video" menu item in the application line is activated, the video application last executed is started. Should another video application be started, then a change must be made to the main menu line again and the "Video" menu item selected. The following submenu items are available:
^ "TV"
^ "DVD-V"
^ "Aux"
^ "Video OFF"

The "Video OFF" menu item switches the video sources off.

"DVD-V" menu item (video DVD)
If a video-DVD is inserted in the DVD-drive, then the following adjustment options appear in the submenu line when the "DVD-V" menu item is activated:
^ "DVD-V"
Setting menu (DVD functions, brightness, contrast, color, picture format)
^ "Pause/Play"
Temporarily interrupts playback
^ "Stop"
Stops playback
^ "Changer", with code (814) DVD changer
List of the CDs/DVDs loaded in the changer
^ "Sound"
Setting menu for sound properties

The DVD video picture is simultaneously displayed in the main menu selection range.

"TV" menu item
If the "TV" menu item has been activated and the TV combination tuner (analog/digital) (A90/1) is ready, the following functions can be selected in the submenu line:
^ "TV"
Setting menu (TV functions, brightness, contrast, color, picture format)
^ "Memory"
^ "Info"
^ "Video text"
Setting menu for video text
^ "Sound"
Setting menu for sound properties

The TV picture is simultaneously displayed in the main menu selection range.

All video sources can be operated when the vehicle is stationary. For safety reasons, no video image is displayed when the vehicle is moving at speeds above 5 km/h.
