GF27.57-P-1000AHV Oil Supply For Automatic Transmission, Function

GF27.57-P-1000AHV Oil Supply For Automatic Transmission, Function
- TRANSMISSION 722.930 in MODEL 204.0 /2 /3

Function requirements for automatic transmission oil supply, general

^ Circuit 87 (connected circuit 15) ON
^ Circuit 61 (engine running)

Oil supply for automatic transmission, general

With the combustion engine running, the oil pump (primary pump) delivers oil to the electrohydraulically actuated transmission. The oil pump drive is provided through the wet clutch's drive spigot. The oil pump is installed in the transmission bell housing behind the wet clutch.
